Product Specifications
Cable AC line
length voltage Rise time
[m] [V] [μs]
15 480 0.288
100 480 0.492
150 480 0.468
Table 6.27 P22KT4
Cable AC line
length voltage Rise time
[m] [V] [μs]
5 480 0.368
50 480 0.536
100 480 0.680
150 480 0.712
Table 6.28 P30KT4
Cable AC line
length voltage Rise time
[m] [V] [μs]
5 480 0.368
50 480 0.536
100 480 0.680
150 480 0.712
Table 6.29 P37KT4
Cable AC line
Rise time
length voltage
[m] [V] [μs]
15 480 0.256
50 480 0.328
100 480 0.456
150 480 0.960
Table 6.30 P45KT4
380–500 V (T5)
Cable AC line
length voltage Rise time
[m] [V] [μs]
5 480 0.371
Table 6.31 P55KT5
Cable AC line
length voltage Rise time
[m] [V] [μs]
5 480 0.371
Table 6.32 P75KT5
MG33BF22
Design Guide
Upeak dU/dt
[kV] [kV/μs]
3.083
1.230 2.000
1.190 2.034
Upeak dU/dt
[kV] [kV/μs]
1.270 2.853
1.260 1.978
1.240 1.426
1.200 1.334
Upeak dU/dt
[kV] [kV/μs]
1.270 2.853
1.260 1.978
1.240 1.426
1.200 1.334
dU/dt
Upeak
[kV] [kV/μs]
1.230 3.847
1.200 2.957
1.200 2.127
1.150 1.052
Upeak dU/dt
[kV] [kV/μs]
1.170 2.523
Upeak dU/dt
[kV] [kV/μs]
1.170 2.523
Rev. 2014-04-04 All rights reserved.
600 V (T6)
Cable AC line
Rise time
length voltage
[m] [V] [μs]
36 600 0.304
50 600 0.300
100 600 0.536
150 600 0.576
Table 6.33 P15KT6
Cable AC line
Rise time
length voltage
[m] [V] [μs]
36 600 0.084
50 600 0.120
100 600 0.165
150 600 0.190
Table 6.34 P30KT6
Cable AC line
length voltage Rise time
[m] [V] [μs]
15 600 0.276
Table 6.35 P75KT6
525–690 V (T7)
Cable AC line
Rise time
length voltage
[m] [V] [μs]
80 690 0.58
130 690 0.93
180 690 0.925
Table 6.36 P7K5T7
Cable AC line
Rise time
length voltage
[m] [V] [μs]
6 690 0.238
50 690 0.358
150 690 0.465
Table 6.37 P45KT7
dU/dt
Upeak
[kV] [kV/μs]
1.560 4.105
1.550 4.133
1.640 2.448
1.640 2.278
dU/dt
Upeak
[kV] [kV/μs]
1.560 7.962
1.540 5.467
1.472 3.976
1.530 3.432
Upeak dU/dt
[kV] [kV/μs]
1.184 4.290
dU/dt
Upeak
[kV] [kV/μs]
1.728 2369
1.824 1569
1.818 1570
dU/dt
Upeak
[kV] [kV/μs]
1416 4739
1764 3922
1872 3252
