Danfoss VLT AutomationDrive FC 301 Series Design Manual page 105

How to Order
FC 302
Adjustable frequency drive data
Line P
m
R R
min
power
(hp
[Ω]
type [kW])
0.34
T2 380 475.3
[0.25]
0.5
T2 275 320.8
[0.37]
0.75
T2 188 215.7
[0.55]
1.0
T2 130 158.1
[0.75]
T2 1.5 [1.1] 81.0 105.1
T2 2 [1.5] 58.5
T2 3 [2.2] 45.0
T2 4 [3] 31.5
T2 5 [3.7] 22.5
T2 7.5 [5.5] 17.7
T2 10 [7.5] 12.6
T2 15 [11] 8.7
T2 20 [15] 5.3
T2 25 [18.5] 5.1
T2 30 [22] 3.2
T2 40 [30] 3.0
T2 50 [37] 2.4
Table 7.11 T2, Vertical Braking 40% Duty Cycle
MG33BF22
Design Guide
R P
rec br.cont.
br.nom
[Ω] [kW]
[Ω]
410 0.100
300 0.200
200 0.200
145 0.300
100 0.450
76.0 70 0.570
51.0 48 0.960
37.0 35 1.130
29.7 27 1.400
19.7 18 2.200
14.3 13.0 3.200
9.7 9.0 5.500
7.5 5.7 6.000
6.0 5.7 8.000
5.0 3.5 9.000
3.7 3.5 14.000
3.0 2.8 17.000
Rev. 2014-04-04 All rights reserved.
Vertical braking 40% duty cycle
Brake resistor data
Danfoss part number
Screw Screw
Wire IP54 terminal terminal
IP21 IP65
175u3004 - -
175u3096 - -
175u3008 - -
175u3300 - -
175u3301 175u3402 175u3401
175u3302 175u3404 175u3403
175u3303 175u3406 175u3405
175u3304 175u3408 175u3407
175u3305 175u3410 175u3409
175u3306 175u3412 175u3411
175u3307 175u3414 175u3413
- 175u3176 175u3177
- - -
- - -
- - -
- - -
- - -
Installation
Cable
Thermo
cross-
Bolt
relay
section
connection
[A]
[mm 2 ]
IP20
- 1.5 0.5
- 1.5 0.8
- 1.5 0.9
- 1.5 1.3
- 1.5 2
- 1.5 2.7
- 1.5 4.2
- 1.5 5.4
- 1.5 6.8
- 1.5 10.4
- 2.5 14.7
- 4 23
175u3233 10 33
175u3234 10 38
175u3235 16 51
175u3224 25 63
175u3227 35 78
103
7 7
