Electrical Installation
Power Bussmann
[kW] Type RK1
(hp [kW])
1.5 [1.1] KTS-R-5
2–3 KTS-R-10
[1.5–2.2]
4 [3] KTS-R15
5 [4] KTS-R20
7.5 [5.5] KTS-R-25
10 [7.5] KTS-R-30
15 [11] KTS-R-35
20 [15] KTS-R-45
24 [18] KTS-R-50
30 [22] KTS-R-60
40 [30] KTS-R-80
50 [37] KTS-R-100
60 [45] KTS-R-125
75 [55] KTS-R-150
100 [75] KTS-R-175
Table 9.15 525–690 V, Enclosure Types A, B and C
Bussmann
Power Max.
E52273
[kW] prefuse
RK1/JDDZ
15 [11] 30 A KTS-R-30
20–25 [15– 45 A KTS-R-45
18.5]
30 [22] 60 A KTS-R-60
40 [30] 80 A KTS-R-80
50 [37] 90 A KTS-R-90
60 [45] 100 A KTS-R-100
75 [55] 125 A KTS-R-125
100 [75] 150 A KTS-R-150
Table 9.16 525–690 V, Enclosure Types B and C
MG33BF22
Design Guide
Recommended max. fuse
Bussmann Bussmann
Type J Type T
JKS-5 JJS-6
JKS-10 JJS-10
JKS-15 JJS-15
JKS-20 JJS-20
JKS-25 JJS-25
JKS-30 JJS-30
JKS-35 JJS-35
JKS-45 JJS-45
JKS-50 JJS-50
JKS-60 JJS-60
JKS-80 JJS-80
JKS-100 JJS-100
JKS-125 JJS-125
JKS-150 JJS-150
JKS-175 JJS-175
Recommended max. fuse
Bussmann Bussmann
E4273 E4273
J/JDDZ T/JDDZ RK1/JDDZ
JKS-30 JKJS-30 5017906-030
JKS-45 JJS-45 5014006-050
JKS-60 JJS-60 5014006-063
JKS-80 JJS-80 5014006-080
JKS-90 JJS-90 5014006-100
JKS-100 JJS-100 5014006-100
JKS-125 JJS-125 2028220-125
JKS-150 JJS-150 2028220-150
Rev. 2014-04-04 All rights reserved.
Bussmann Bussmann
Type CC Type CC
FNQ-R-5
FNQ-R-10 KTK-R-10
FNQ-R-15 KTK-R-15
FNQ-R-20 KTK-R-20
FNQ-R-25 KTK-R-25
FNQ-R-30 KTK-R-30
-
-
-
-
-
-
-
-
-
SIBA Littelfuse
E180276 E81895
RK1/JDDZ
KLS-R-030
KLS-R-045
KLS-R-060
KLS-R-075
KLS-R-090
KLS-R-100
KLS-150
KLS-175
Bussmann
Type CC
KTK-R-5 LP-CC-5
LP-CC-10
LP-CC-15
LP-CC-20
LP-CC-25
LP-CC-30
- -
- -
- -
- -
- -
- -
- -
- -
- -
Ferraz- Ferraz-
Shawmut Shawmut
E163267/E2137 E2137
RK1/JDDZ J/HSJ
A6K-30-R HST-30
A6K-45-R HST-45
A6K-60-R HST-60
A6K-80-R HST-80
A6K-90-R HST-90
A6K-100-R HST-100
A6K-125-R HST-125
A6K-150-R HST-150
