How to Order
FC 301
Adjustable frequency drive data
Line P
m
R R
min
power
(hp
[Ω]
type [kW])
T4 0.5 [0.37] 1000 1121.4
0.75
T4 620
[0.55]
T4 1.0 [0.75] 485
T4 1.5 [1.1] 329
T4 2 [1.5] 240
T4 3 [2.2] 161
T4 4 [3] 117
T4 5 [4] 86.9
T4 7.5 [5.5] 62.5
T4 10 [7.5] 45.3
T4 15 [11] 34.9
T4 20 [15] 25.3
T4 25 [18.5] 20.3
T4 30 [22] 16.9
T4 40 [30] 13.2
T4 50 [37] 10.6
T4 60 [45] 8.7
T4 75 [55] 6.6
T4 100 [75] 4.2
Table 7.9 T4, Vertical Braking 40% Duty Cycle
MG33BF22
Design Guide
R P
rec br.cont.
br.nom
[Ω] [kW]
[Ω]
1200 0.200
749.8 850 0.200
547.6 630 0.300
365.3 410 0.450
263.0 270 0.570
176.5 200 0.960
127.9 145 1.130
94.6 110 1.700
68.2 80 2.200
49.6 56 3.200
38.0 38 5.000
27.7 28 6.000
22.3 22 8.000
18.7 19 10.000
14.5 14 14.000
11.7 12 17.000
9.6 9.5 21.000
7.8 7.0 26.000
5.7 5.5 36.000
Rev. 2014-04-04 All rights reserved.
Vertical braking 40% duty cycle
Brake resistor data
Danfoss part number
Screw Screw
Wire IP54 terminal terminal
IP21 IP65
175u3101 - -
175u3308 - -
175u3309 - -
175u3310 175u3416 175u3415
175u3311 175u3418 175u3417
175u3312 175u3420 175u3419
175u3313 175u3422 175u3421
175u3314 175u3424 175u3423
175u3315 175u3138 175u3139
175u3316 175u3428 175u3427
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
Installation
Cable
Thermo
cross-
Bolt
relay
section
connection
[A]
[mm 2 ]
IP20
- 1.5 0.4
- 1.5 0.5
- 1.5 0.7
- 1.5 1
- 1.5 1.4
- 1.5 2.1
- 1.5 2.7
- 1.5 3.7
- 1.5 5
- 1.5 7.1
175u3236 1.5 11.5
175u3237 2.5 14.7
175u3238 4 19
175u3203 4 23
175u3206 10 32
175u3210 10 38
175u3213 16 47
175u3216 25 61
175u3219 35 81
101
7 7
