Options and Accessories
Terminal Overview
Terminal number Descriptive Name Encoder 2
(Feedback)
1 +24 V Supply
2 +8 V Supply
3 +5 V Supply
4 GND
5 A
6 A not
7 B
8 B not
9 Z/Clock
10 Z not/Clock not
11 DATA
12 DATA not
Table 11.5 Terminal Block X55
Terminal number Descriptive Name Encoder 1 (Master)
1 +24 V Supply
2 N/A
3 +5 V Supply
4 GND
5 A
6 A not
7 B
8 B not
9 Z/Clock
10 Z not/Clock not
11 DATA
12 DATA not
Table 11.6 Terminal Block X56
Terminal number Descriptive Name Digital inputs
1 Digital Input
2 Digital Input
3 Digital Input
4 Digital Input
5 Digital Input
6 Digital Input
7 Digital Input
8 Digital Input
9 Digital Input
10 Digital Input
Table 11.7 Terminal Block X57
Terminal number Descriptive Name Supply
1 +24 V Supply
2 GND
Table 11.8 Terminal Block X58
MG33BF22
Design Guide
Terminal number
1
2
3
4
5
6
7
8
Table 11.9 Terminal Block X59
Terminal number
1
CS
62
63
66
67
Table 11.10 Terminal Block X60
Terminal number
1
2
3
4
5
Table 11.11 Terminal Block X62
11.3.1 VLT
The MCO 305 is an integrated free programmable motion
controller for FC 301 and FC 302, for more information, see
chapter 11.3.1 Motion Control Options.
11.3.2 VLT
NOTICE!
Terminal block X59 has fixed functionality for MCO 350.
NOTICE!
Terminal block X62 is not supported for MCO 350.
NOTICE!
Terminal block X60 is not used for MCO 350.
For more information, see chapter 11.3.1 Motion Control
Options.
Rev. 2014-04-04 All rights reserved.
Descriptive Name Digital outputs
Digital Output/Input
Digital Output/Input
Digital Output
Digital Output
Digital Output
Digital Output
Digital Output
Digital Output
MCO Debug (RS-485)
Control Select
RxD/TxD - P
RxD/TxD - N
0 V
+5 V
MCO CAN Bus
N/A
CAN - L
DRAIN
CAN - H
N/A
®
Motion Control Option MCO
305
®
Synchronizing Controller MCO
350
11 11
