Cable Specifications for Console and Management Connections for the
QFX Series
Table 35 on page 84 lists the specifications for the cables that connect the QFX Series switch to a
management device.
NOTE: The QFX Series can be configured with SFP management ports that support 1000BASE-
SX transceivers. See the
for use with these transceivers.
Table 35: Cable Specifications for Console and Management Connections for the QFX Series
Port on QFX Series Cable Specification
Device
Console port RS-232 (EIA-232) serial
cable
Management port Category 5 cable or
equivalent suitable for
1000BASE-T operation
RJ-45 Management Port Connector Pinout Information
Table 36 on page 84 provides the pinout information for the RJ-45 connector for the management port
on Juniper Networks devices.
Table 36: RJ-45 Management Port Connector Pinout Information
Pin
1
Hardware Compatibility Tool
Cable Supplied
One 7-foot (2.13-meter)
long RJ-45 patch cable
and RJ-45 to DB-9
adapter
One 7-foot (2.13-meter)
long RJ-45 patch cable
Signal
TRP1+
for more on the fiber-optic cables required
Maximum Length
7 feet
(2.13 meters)
328 feet
(100 meters)
Description
Transmit/receive data pair 1
84
Device
Receptacle
RJ-45
RJ-45
