Juniper QFX5200 Hardware Manual page 55

of the LEDs on the QFX5200-32C power supply.
QFX5200-48Y power supply.
Figure 26: AC Power Supply LEDs on QFX5200-32C and QFX5200-32C-L Switches
Figure 27: AC Power Supply LED on a QFX5200-48Y Switch
Bi-colored LED
1
—
Table 20 on page 46 and
Table 20: AC Power Supply LEDs on QFX5200-32C and QFX5200-32C-L
LED Color State
AC OK Unlit Off
Green On steadily
Table 21 on page 47 describe the LED behavior on the AC power supplies.
Description
The power supply is disconnected from power, or power is not coming into the
power supply.
Power is coming into the power supply.
Figure 27 on page 46 shows the LED location on a
46
