Connecting Ac Power To A Qfx5200 - Juniper QFX5200 Hardware Manual

two-holed grounding lug, you can ground the chassis using the DC protective earthing terminal on the
DC power supply.
The DC power supplies have a protective earthing terminal on the face that holds an M5 pan-head
screw with integrated washer. See
Figure 50: DC Power Supply Faceplate on a QFX5200-32C-DC
1 Shunt negative input terminals (-48V)
—
Shunt positive input terminals (+RTN)
2
—
3 Terminal block
—
4 Security latch
—

Connecting AC Power to a QFX5200

Ensure that you have a power cord appropriate for your geographical location available to connect AC
power to the switch.
Figure 50 on page 112.
5 Protective earthing terminal
—
Fault LED
6
—
7 Output LED
—
8 Input LED
—
