Table 10: Console Port LED on a QFX5200-32C and QFX5200-32C-L
LED
Status
QFX5200-48Y Management Panel
The management panel of the QFX5200-48Y is found on the port panel next to right of the quad small-
form factor pluggable plus (QSFP28) ports. See
Figure 10: QFX5200-48Y Port Panel
1 48 SFP28 ports
—
4 QSFP28 ports
2
—
3 RJ45 management port
—
4 RJ45 console
—
Color
Unlit
Green
Figure 10 on page 22
State
Off
On steadily
to locate the management panel.
5 2 QSFP28 ports
—
USB port
6
—
7 System status LEDs
—
Description
The console is off.
The console is on.
