Table 40: SFP+ Network Port Connector Pinout Information
Pin Signal
16 VccT
17 VeeT
18 TD+
19 TD-
20 VeeT
Table 41: QSFP+ and QSFP28 Network Port Connector Pinout Information
Pin
1
2
3
4
5
6
7
8
9
Description
Module transmitter 3.3-V supply
Module transmitter ground
Transmitter noninverted data input
Transmitter inverted data input
Module transmitter ground
Signal
GND
TX2n
TX2p
GND
TX4n
TX4p
GND
ModSelL
LPMode_Reset
(Continued)
