Juniper QFX5200 Hardware Manual page 133

• For standard Junos OS systems:
[edit]
root@# set interfaces em0 unit 0 family inet address
• For Junos OS Evolved systems:
[edit]
root@# set interfaces re0:mgmt-0 unit 0 family inet address
CAUTION: Although the CLI permits you to configure two management Ethernet
interfaces within the same subnet, only one interface is usable and supported.
NOTE: On the QFX5200-48Y, the management port em0 is the top right-hand RJ-45 port on
the port panel.
9. (Optional) Configure the static routes to remote prefixes with access to the management port.
[edit]
root@# set routing-options static route remote-prefix next-hop
readvertise
10. Enable services such as SSH and Telnet.
NOTE: You will not be able to log in to the switch as the root user through Telnet. Root login
is allowed only through SSH.
• The default option for SSH is yes. Select this to enable SSH.
• The default option for Telnet is no. Change this to yes to enable Telnet.
ip-address/prefix-length
ip-address/prefix-length
destination-ip retain no-
124
