QFX5200-32C and QFX5200-32C-L Chassis Status LEDs
The QFX5200-32C and QFX5200-32C-L have four status LEDs on the FRU side of the chassis, next to
the management ports (see
Figure 12: Locating Chassis Status LEDs on a QFX5200-32C and QFX5200-32C-L
Status LEDs
1
2
em0–RJ-45 (10/100/1000 BASE-T)
management Ethernet port (C0)
3
RJ-45 console port (CON) )
Table 13 on page 25
describes the chassis status LEDs on a QFX5200-32C and QFX5200-32C-L, their
colors and states, and the status they indicate. You can view the colors of the three LEDs remotely
through the CLI by issuing the operational mode command show chassis lcd.
Table 13: Interpreting Chassis Status LEDs on a QFX5200-32C and QFX5200-32C-L
Name
ALM–Alarm or beacon
Figure 12 on page
25).
Color
State
Unlit
Off
USB port
4
5
em1–SFP management Ethernet port (C1)
Cage (socket for either 10/100/1000 Base-T
RJ45 SFP or 1GbE fiber SFP)
Description
The switch is halted or there is no
alarm.
25
