1.7.2 System Menu Reference

Press [Shift]+[Display] (System) to enter into the system menu interface.
System System Menu
Beep
PowerOn
Comm
•
On: Turn the sense function on.
Set the Bleeder circuit state (When testing the battery, the user
need to turn the Bleeder circuit off)
•
On: Turn the Bleeder circuit on.
•
Off: Turn the Bleeder circuit off.
Set the trigger source
Keypad
Bus
Ext
Set the key beeper state.
Turn the key beeper off.
Off
Turn the key beeper on.
On
Select the power-on state.
When the power supply is powered on, the power supply will
Reset
initialize some settings and output state.
When the power supply is powered on, the power supply will
remain the same settings and output state as last time you
Last
turned off the power supply.
When the power supply is powered on, the power supply will
remain the same settings as last time you turned off the power
Last+Off
supply, but the output state is OFF state.
Set the communication information between instrument and PC. (The menu
displays different interfaces information automatically based on the inserted
communication board.)
No optional communication interfaces.
None
When insert IT-E1205 communication board into expansion
GPIB
slot, the menu displays this information.
General purpose interface bus (GPIB) communication
interface.
Copyright © Itech Electronic Co., Ltd.
Keypad trigger, [Shift]+[On/Off]
(Trigger)
Remote interface trigger command,
like *TRG
External trigger, when the TRIG± inter-
face state is set to IN and receive a
high pulse signal, the instrument gen-
erates trigger.
Quick Reference
