1. Remove the output terminal cover.
2. Loosen the screws of the output terminals and connect the red and black
3. Refer to the wiring diagram, and use shielded twisted-pair cables to connect
4. Thread the red and black test cables and sense cables through the output
5. Connect the other end of the remote sense cables and the red and black ca-
6. Power on the instrument and turn the sense function on. Please refer to

2.7 Connect the Communication Interface

This series power supply has no standard-equipped communication interfaces.
Users can purchase communication cards separately. Users can choose one of
To ensure the stability of the system, use shielded twisted-pair cables be-
tween the remote sense terminals and the equipment under test.
test cables to the output terminals, and connect the ground terminal cor-
rectly. Re-tighten the screws.
When maximum current that one test cable can withstand fails to meet the
current rated current, use multiple pieces of red and black test cables. For
example, the maximum current is 1,200 A, then 4 pieces of 360 A red and
black cables are required.
the remote sense terminals and the equipment under test.
terminals cover and install the cover.
bles to the DUT. The positive and negative poles must be properly con-
nected and fastened when wiring.
4.1.3 Set the Sense Function State
Copyright © Itech Electronic Co., Ltd.
Inspection and Installation
for the detailed operations.
