Bleeder
Trig Source

1.7.2 System Menu Reference

Press [Shift]+[Display] (System) to enter into the system menu interface.
System System Menu
Beep
PowerOn
Connect
•
On: Turn the sense function on.
Set the Bleeder circuit state (When testing the battery, the user
need to turn the Bleeder circuit off)
•
On: Turn the Bleeder circuit on.
•
Off: Turn the Bleeder circuit off.
Set the trigger source
Keypad
Bus
Ext
Set the key beeper state.
Turn the key beeper off.
Off
Turn the key beeper on.
On
Select the power-on state.
When the power supply is powered on, the power supply will
Reset
initialize some settings and output state.
When the power supply is powered on, the power supply will
remain the same settings and output state as last time you
Last
turned off the power supply.
When the power supply is powered on, the power supply will
remain the same settings as last time you turned off the power
Last+Off
supply, but the output state is OFF state.
Set the working mode of the two channels of the instrument.
Configure the instrument to 2-channel independent output
Single
mode.
Configure the instrument to 2-channel parallel mode.
Parallel
Configure the instrument to 2-channel series mode.
Series It is forbidden to output more than 100V voltage after two
channels are connected in series.
Copyright © Itech Electronic Co., Ltd.
Keypad trigger, [Shift]+[On/Off]
(Trigger)
Remote interface trigger command,
like *TRG
External trigger, when the TRIG± inter-
face state is set to IN and receive a
high pulse signal, the instrument gen-
erates trigger.
