Set the communication address within the range from 0 to 30.
When insert IT-E1206 communication board into expansion
USB+LAN
slot, the menu displays this information.
USB
LAN
Copyright © Itech Electronic Co., Ltd.
Universal serial bus (USB) communication inter-
face. (When insert IT-E1209 communication
board into expansion slot, the menu displays this
information.)
USB-TMC protocol
TMC
Virtual serial port
VCP
LAN communication interface.
Lan Info View the LAN information.
•
Status
•
IP Mode Status
•
IP Addr
•
Sub Net
•
Gateway
•
DNS1 (Primary address)
•
DNS2 (Secondary address)
•
MAC Addr
•
Host Name
•
Host Desc
•
Domain
•
TCPIP INSTR
•
Socket Port
Lan Config Configure LAN information.
IP Mode
Quick Reference
Set IP mode.
Auto: automatically con-
figure the address of the
instrument.
Manual: manually con-
figure the address of the
instrument by entering
values in the following
six fields.
The following informa-
tion only appear when
Manual is selected.
•
IP Addr
•
Sub Net
