Turning the POWER Switch Off
Flip the POWER switch to the ( O ) side to turn the instrument off. When it is
turned off, the instrument interface will prompt "Power Down", and the instru-
ment will store the setting information before shutdown in the group 1 non-vola-
tile memory.
After you turn the POWER switch off, wait at least 10 seconds after the fan
stops before you turn the POWER switch back on. Turning the instrument on
too soon after you turn it off can cause damage to the inrush current limiter cir-
cuit, as well as reduce the life of components such as the POWER switch and
the internal input fuses.

3.2 Set the Output Voltage

The voltage setting range is from 0 V to the maximum rated output voltage.
When [V-set] key is pressed, the key light is lit and the output voltage value can
be set. Press right and left keys to move the cursor and rotate the knob to adjust
the voltage value in voltage setting filed.

3.3 Set the Output Current

The current setting range is from 0 A to the maximum rated output current.
When [I-set] key is pressed, the key light is lit and the output current value can
be set. Press right and left keys to move the cursor and rotate the knob to adjust
the current value in current setting filed.

3.4 Set the Output Power

Power settings range from 0W to full rated output power. When the actual
output power reaches the set value, the power supply enters the CP output
mode. The setting method is as follows:
1. Press [Shift]+[V-set] (Config) to enter the configuration menu page.
2. Use the knob or press the left and right direction keys to select P-Set, press
The instrument takes approximately 30 seconds to initialize before it is ready
for use.
[Enter] to confirm, and enter the setting interface.
