1.3 Keyboard Introduction

The keyboard introduction of IT-M3100D series power supplies is shown as
follows.
Keys
CH1
CH2
[On/Off]
[V-set]
[I-set]
[Display] Display the measurement value
[ALL On/
Off]
[Esc]
[Enter]
Composite key [Shift], combined with other keys to realize functions marked
above keys. The detailed functions are listed as follows.
Description
Switch channels.
Turns the instrument output on or off. When lit, indicates that the
output is enabled or on.
Sets the output voltage value.
Sets the output current value.
Simultaneously turns on/off the outputs of both channels.
Returns to the previous menu level.
Selects the menu item or confirm an operation.
Moves the cursor below the setting value or scrolls pages to view
menu items.
