ITech IT-M3100D Series User Manual page 105

Model Specifica-
IT-E32410-OO
IT-E32420-OO
IT-E33620-OO
For maximum current of AWG copper wire, refer to table below.
AWG 8 10
The
Maxi-
mum
60 40
Current
Value (A)
•
AWG (American Wire Gage), it means X wire (marked on the wire). The table
above lists current capacity of single wire at working temperature of 30°C. For
reference only.
•
Along with temperature, you must also consider voltage drop when selecting
wire sizes.
Although the instrument will compensate for the voltage in the wires, it is recom-
mended to minimize the voltage drop as much as possible to prevent excessive
power consumption from the instrument and poor dynamic response to load
changes. Larger diameter wire sizes will help minimize wire voltage drops. Twist-
ing or bundling wires will help reduce transient voltage drops.
Copyright © Itech Electronic Co., Ltd.
Length
tion
240A 1m
240A 2m
360A 2m
12 14 16
30 20 13
Description
A pair of red and black test ca-
bles with round terminals at both
ends
A pair of red and black test ca-
bles with round terminals at both
ends
A pair of red and black test ca-
bles with round terminals at both
ends
18 20 22 24
10 7 5 3.5
Appendix
26 28
2.5 1.7
94
