1.5 Prompt Information Reference

The instrument provides detailed prompt information to help the user learn the
function well.
Prompt Information
Ri
System Selftest
Switch To Master Mode
Name Description
Output values Displays the present output voltage and current
view area values.
Setting values Shows the present setting voltage and current val-
view area ues. You can change these values by pressing the
[V-set] and [I-set] keys on the front panel.
Output status Displays the present output status. The power supply
always has one of the following status visible:
•
OFF: The output is turned off.
•
CC: The output is turned on and the power supply
is in constant current (CC) mode.
•
CV: The output is turned on and the power supply
is in constant voltage (CV) mode.
•
CP: The output is turned on, the power supply is
in constant power mode.
•
time or output-off delay time.
Copyright © Itech Electronic Co., Ltd.
: the power supply is in the output-on delay
Description
Indicates output delay time
Indicates the key is locked.
Indicates the instrument is in remote
control.
Indicates the output is self-locked.
Indicates the instrument is running the sys-
tem selftest.
Indicates the instrument is switching to the
master mode.
