Name Description
Baud rate Select the baud rate from the following options: 4800,
9600, 19200, 38400, 57600, 115200
Data Bit 8 (fixed)
Parity bit None (fixed)
Stop bit 1 (fixed)
The operation steps are as follows.
1. Press [Shift]+[Display] (System) to enter into the system menu interface.
2. Use left and right keys or rotate the knob to select Comm and press [Enter]
key to confirm.
3. Use left and right keys or rotate the knob to select RS485 and press [Enter]
key to confirm.
RS485
9600_8_None_1
4. Rotate the knob to set the baud rate.
5. After finishing the setting, press [Esc] to exit.
