4. Operate the front panel of one unit in the System Bus link and set the syn-

4.4 Protection Function

This series power supplies provide the following protection functions. You can
set these functions in the Protect menu.
•
•

4.4.1 Set the Setting Value Limit Protection

To avoid causing damage to the DUT, after you set the U-Max, U-Min, the set-
ting value from the [V-set] key on the front panel can't exceed the setting limit.
The operation steps are as follows.
1. Press [Shift]+[Esc] (Protect) to enter Protect menu interface.
2. Use left and right keys or rotate the knob to select U-Max, U-Min, and press
3. Rotate the knob to adjust the value and press [Enter] key to confirm.
4. Press [Esc] to exit the protection menu setting.
chronization mode (other units modes will be modified simultaneously).
a. Press [Shift]+[Display] (System) to enter into the system menu
interface.
b. Use left and right keys or rotate the knob to select Link and press
[Enter] key to make the parameter in modification.
c. Rotate the knob to set Mode and press [Enter] key to confirm.
•
OnOff Only
•
Track→Reference
If you select Track mode, you need to set the Reference value of
each unit in the System Bus link.
•
Duplicate
The maximum output voltage setting value (U-Max), the minimum output
voltage setting value (U-Min), these functions limit the setting value of the
output voltage from front panel.
Over-voltage protection, over-current protection, over-power protection, and
over-temperature protection, these functions disable the output to protect
the device under test (DUT), as well as the power supply.
[Enter] key to confirm.
