M3132D - ITech IT-M3100D Series User Manual

Isolation ( output to ground)
Isolation (input to ground)
Working Temperature
Production Compliance
Dimensions without legs and terminals (mm)
Overall dimension (mm)
5.2 IT-M3132D
Rated value
Line Regulation ±(％of Out-
put+Offset)
Load Regulation ±(％of Out-
put+Offset)
Setup Resolution
Read Back Resolution
Setup Accuracy
Parameter
Fuse Specifications
Parallel Number
Series Number
Ingress Protection
Cooling
Weight( net)
Parameter
Voltage
Current
Power
Resistance
Voltage
Current
Voltage
Current
Voltage
Current
Power
Resistance
Voltage
Current
Power
Voltage
Copyright © Itech Electronic Co., Ltd.
Model: IT-M3131D CH1 & CH2
400Vdc
1500Vac
0～40℃
T15A
IP20
IEC 61010
Air cooling
214mmW*43.5mmH*450mmD
234mmW*476mmD*52.9mmH
(5±0.5)kg
Model: IT-M3132D CH1/CH2
0～60V
0～10A
0～200W
≤0.02%+0.005%FS
≤0.05%+0.01%FS
≤0.01%+0.008%FS
≤0.05%+0.05%FS
1mV
1mA
1W
1mV
1mA
1W
≤0.03% + 0.02%FS
Specification
≤1
≤1
\
\
81
