need to set voltage or current, slope and dwell time for each step. The user also
can set repeat times, end state and so on for each list program.
The descriptions of list function menu are listed in the table below.
List Mode List mode
Run List
Apply
Channel
Recall List
Edit List
In the channel combination mode Combine, the List function is
unavailable.
Turn the list mode on/off.
On Turn the list mode on.
Off Turn the list mode off.
Select channel as CH1 or CH2
Select a list program to view.
List Setup View the setting parameters of the selected list
program.
View Step Select the desired step to view.
Edit list program.
List Setup Set the list program.
Mode
End State
Repeat
Edit Step Edit parameters for each step.
Current/
Voltage
Slope
Copyright © Itech Electronic Co., Ltd.
Functions and Features
Set the operation mode for list program.
•
CC: current mode;
•
CV: voltage mode.
Set the running state after the list pro-
gram is running over.
•
Normal: keep outputting the voltage
and current setting in main interface
when the dwell time is over.
•
Last: keep outputting the last step
when the dwell time is over.
Set the number of loops to run the List
file, range: 1–65535. Set to 65535 to run
in an infinite loop.
Current value or voltage value.
(The voltage appears when CV mode is
selected; the current appears when CC
mode is selected.)
Slope value (0.001~3600), unit: second.
