Set the instruments to parallel operation mode.
Parallel
Single
Combine
Set the instruments to synchronized operation mode.
Link
Status
Mode
Chan
Set channel number value: 1, 3, 5, 7, 9, 11, 13, 15.
Number
Set the rear panel interface TRIG± function.
Ext IO
Trig Out
Trig In
Sync Out
Copyright © Itech Electronic Co., Ltd.
•
Select the baud rate from the following op-
tions: 4800, 9600, 19200, 38400, 57600,
115200.
•
The data bit, parity bit and stop bit are fixed:
8_None_1.
Configure the instrument to 2-channel independent output
mode.
Configure the instrument to 2-channel parallel mode.
Set the synchronized state. Same function as the [Link] key.
Offline Disable the Link function.
Online Enable the Link function.
Set the synchronized mode.
On/Off Set multiple units to output on/off and Save/Recall
Only synchronization.
Track Set multiple units to output on/off, Save/Recall
synchronization and voltage proportional
changing.
Reference
Duplicate Set multiple units to output on/off synchronization,
voltage/current setting value changing synchroni-
zation, Save/Recall synchronization, priority
mode synchronization, voltage/current rising/fall-
ing synchronization and Protect menu function
synchronization.
When the trigger source is set to Keypad or Bus and the trig-
ger happens, the TRIG± interface generates a high pulse trig-
ger signal.
When the trigger source is set to Ext, inputting a high pulse
trigger signal through TRIG± interface can trigger the
instrument
By default, it is used as the indicator signal of the output state
of the instrument. Channels can be selected via submenus.
•
CH1: Select channel 1.
•
CH2: Select channel 2.
The On/Off light is off, the pin outputs 0V low level; the On/Off
light is on, the pin outputs 5V high level.
Quick Reference
Set the voltage proportional relation-
ship among multiple units.
