Printhead Replacement, cont.
3
Remove the media (and ribbon).
5
Disconnect the printhead bracket from the print
mechanism as indicated by the arrows and pull out
the printhead as far as the cables allow.
Intermec EasyCoder F2 – User's Guide
Chapter 11
4
Pull the printhead bracket away from the magnet
in the pressure arm.
6
Disconnect the cables from the printhead. Note
the snap-lock on the inner connector. Pull at the
connectors–not at the cables!
Maintenance
Snap-Lock
