Chapter 3 Starting Up

Switching On the Printer

Display Messages at Startup

20
Before switching on the printer, make the necessary connections,
insert any memory card you want to use, and check that the
printhead is engaged.
Switch on the power using the On/Off switch on the rear plate.
The "Power" control lamp on the front panel lights up when the
power is on. Wait for a few moments, while the printer loads
the program and runs some self-diagnostic tests. Then some kind
of message will appear in the display window, depending on the
startup fi le.
When the power is switched on, the printer is initialized. The
progress of the initialization is indicated by an increasing number
of colons on the lower line in the display:
Initializing
:::
The type of startup fi le running in the printer is indicated by
the message shown in the display window immediately after
initialization.
A. Intermec Shell Startup Program (standard printers)
ENTER=SHELL
5 sec. v.4.8
4 sec.
3 sec.
Refer to Chapter 8 for more information on Intermec Shell. The
digits in the lower right corner of the display indicate the version
of Intermec Shell.
B. Custom-Made Application Program (non-standard printers)
Any other display messages than those illustrated above indicates
that the printer is running some custom-made, non-standard
application program, or that some error has occurred.
v.4.8
v.4.8
2 sec. v.4.8
1 sec.
