Setup Parameters, cont.
Media, cont.
Intermec EasyCoder F2 – User's Guide

Paper Type

The Paper Type parameters control the heat emitted from the
printhead to the direct thermal media or, optionally, the transfer
ribbon in order to produce the dots that make up the printout
image. Start by choosing between two alternatives:
• Direct Thermal printing (default)
• Thermal Transfer printing (option)
Your choice will decide which parameters to enter next:
Direct Thermal Printing
This option contains two parameters:
• Label Constant
• Label Factor
Thermal Transfer Printing (option)
This option contains four parameters:
• Ribbon Constant
• Ribbon Factor
• Label Offset
1
• Low Diameter
1
/. This parameter specifi es the diameter of the ribbon supply roll,
where SYSVAR(26) switches from 0 to 1.
SYSVAR(26) = 0 means that there is still a suffi cient supply of
ribbon, whereas SYSVAR(26) = 1 means that it is time to consider
replacing the ribbon supply.
The diameter is expressed in millimetres and an accuracy of ±3
mm can be expected. Note that this setting has no effect unless
SYSVAR(26) is read by a Fingerprint program (v7.40 or later).
Chapter 6 Setting Up the Printer
(range 50 to 115)
(range 10 to 50)
(range 50 to 115)
(range 10 to 50)
(range -50 to 50)
(range 25 to 80 mm)
45
