Troubleshooting - Intermec EasyCoder F2 User Manual

Chapter 10

Troubleshooting

Symptom
Overall weak printout
Printout weaker on one side
Weak spots
Overall dark printout
Excessive bleeding
Dark lines along media path
White lines along media path
Large part of dot line missing
Printout missing along inner edge Bad media alignment
Transfer ribbon breaks
Transfer ribbon wrinkles
No thermal transfer printout
Media feed not working properly
Compressed text or bar code
74
Possible Cause
Wrong Paper Type parameter
Contrast value too low
Printhead pressure too low
Worn printhead
Wrong printhead voltage
Uneven printhead pressure
Foreign particles on media
Media/ribbon don't match
Poor media or ribbon quality
Worn printhead
Worn platen roller
Wrong Paper Type parameter
Contrast value too high
Printhead pressure too high
Wrong printhead voltage
Wrong Paper Type
Contrast value too high
Printhead pressure too high
Faulty energy control
Foreign objects on printhead
Printhead dirty
Missing dots on printhead
Wrong X-start or Width parameter
Failing printhead
Failing strobe signal
Small core & supply post in upper pos.
X-start parameter value too low
Ribbon not fi tted correctly
Wrong paper type parameter (too much
energy)
Bad energy control
Faulty ribbon break shaft adjustment
Incorrect edge guide adjustment
Too strong printhead pressure
Ink-coated side does not face media
Changed media characteristics
Wrong start- and stop adjust values
Wrong Media Type parameter
Wrong sensor position
Dirty or blocked sensors
Faulty sensors
Too high print speed for large media roll
Remedy
Change parameter
Change parameter
Adjust
Replace printhead
Replace CPU board
Adjust arm alignment
Clean or replace
Change to matching media
Use Intermec media/ribbon
Replace printhead
Check/replace
Change parameter
Change parameter
Adjust
Replace CPU board
Change parameter
Change parameter
Adjust
Replace CPU board
Clean printhead
Clean printhead
Replace printhead
Change parameter
Replace printhead
Check CPU-board
Adjust
Move post to lower pos.
Increase
Reload ribbon
Change parameter,
then clean printhead
Adjust
Adjust
Adjust
Adjust
Reload ribbon
Perform a TESTFEED
Check/change
Check/change
Check/change
Clean media guides
Replace
Lower print speed
Intermec EasyCoder F2 – User's Guide
Refer to
Chapter 6
Chapter 6
Chapter 12
Chapter 11
¤ Call Service
Chapter 12
Chapters 4 & 5
Chapter 6
Appendix 2
Chapter 11
¤ Call Service
Chapter 6
Chapter 6
Chapter 12
¤ Call Service
Chapter 6
Chapter 6
Chapter 12
¤ Call Service
Chapter 11
Chapter 11
Chapter 11
Chapter 6
Chapter 11
¤ Call Service
Chapter 4
Chapter 2
Chapter 6
Chapter 5
Chapter 6
Chapter 12
¤ Call Service
Chapter 12
Chapter 4
Chapter 12
Chapter 5
Chapter 4
Chapter 6
Chapter 6
Chapter 12
Chapter 11
¤ Call Service
Chapter 6
