Media, cont.

Self-Adhesive Labels

a
c
d
SELF-ADHESIVE
LABELS
b
FEED
DIRECTION
Intermec EasyCoder F2 – User's Guide
⇐ a ⇒ Media Width (including liner):
Maximum:
Minimum (standard):
Minimum (Quick-Load):
⇐ b ⇒ Liner
The backing paper must not extend more than a total of 1.6
mm (0.06 inches) outside the labels and should protrude equally
on both side. Recommended min. transparency: 40% (DIN
53147).
⇐ c ⇒ Label Width (excluding liner):
Maximum:
Minimum:
⇐ d ⇒ Label Length:
Maximum:
Minimum:
e
Under ideal circumstances, a minimum label length of 4 mm (0.16
inches) could be used. It requires the sum of the label length (d) and
the label gap (e) to be larger than 7 mm (0.28 inches), that batch
printing is used, and that no pull back of the media is performed.
Intermec does not guarantee that such short labels will work, but it is
up to the user to test this in his unique application.
⇐ e ⇒ Label Gap:
Maximum:
b
Recommended:
Minimum:
The Label Stop Sensor must be able to detect the extreme front
edges of the labels. It can be moved between 5 fi xed positions at
the following distances from the inner edge of the media.
3 mm
8 mm
12 mm
16 mm
20 mm
Media Type Setup:
• Label (w gaps)
Appendix 2 Media Specifi cations
(0.118 inches)
(0.315 inches)
(0.472 inches)
(0.639 inches)
(0.787 inches)
60.0 mm (2.36 inches)
25.0 mm (1.00 inches)
40.0 mm (1.57 inches)
58.4 mm (2.30 inches)
23.8 mm (0.94 inches)
depends on DRAM size
8.0 mm (0.32 inches)
21.3 mm (0.83 inches)
3.0 mm (0.12 inches)
1.2 mm (0.05 inches)
