Table 3. Speed/Activity LEDs for the 10/100/1000Mbps Copper Ports
State
Off
Table 4 describes the duplex mode LEDs for the 10/100/1000Mbps copper
ports.
Table 4. Duplex Mode LEDs for the 10/100/1000Mbps Copper Ports
State
Solid Green
Solid Amber
Flashing Amber
Off
CentreCOM GS970EMX Series Installation Guide for Standalone Switches
Possible causes of this state are listed
here:
- The port has not established a link with
another network device.
- The LEDs are turned off. To turn on the
LEDs, use the eco-friendly button.
The port is operating in full duplex mode.
The port is operating in half duplex mode.
The port is operating in half duplex mode,
with collisions.
Possible causes of this state are listed
here:
- The port has not established a link with
another network device.
- The LEDs are turned off. To turn on the
LEDs, use the eco-friendly button.
Description
Description
