Page 1: Ethernet Switch
Layer 2 Gigabit Ethernet Switch AT-GS900/8POE Installation Guide 613-000414 Rev. D... - Page 2 Allied Telesis, Inc. reserves the right to make changes in specifications and other information contained in this document without prior written notice. The information provided herein is subject to change without notice. In no event shall Allied Telesis, Inc. be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis, Inc.
-
Page 3: Electrical Safety And Emissions Standards
European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment This Allied Telesis RoHS-compliant product conforms to the European Union Restriction of the Use of Certain Hazardous Substances (RoHS) in Electrical and Electronic Equipment. Allied Telesis ensures RoHS conformance by requiring supplier Declarations of Conformity, monitoring incoming materials, and maintaining manufacturing process controls. -
Page 4: Translated Safety Statements
Translated Safety Statements Important: The indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” posted on the Allied Telesis website at www.alliedtelesis.com and on the documentation CD shipped with this product. -
Page 5: Table Of Contents
Preface ...11 Safety Symbols Used in this Document...12 Where to Find Web-based Guides ...13 Contacting Allied Telesis ...14 Online Support ...14 Email and Telephone Support ...14 Returning Products...14 For Sales or Corporate Information ...14 Warranty ...14 Chapter 1: Overview ...15 Features ...16... - Page 6 Contents Power Specifications...49 Safety and Electromagnetic Emissions Certifications...50 RJ-45 Twisted Pair Port Connectors...51...
- Page 7 Figures Figure 1. AT-GS900/8POE Gigabit Ethernet Switch Front and Back Panels ...16 Figure 2. SFP Transceiver...18 Figure 3. Power Workgroup Topology ...27 Figure 4. PoE Network Topology...28 Figure 5. Attaching the Rubber Feet ...35 Figure 6. Attaching Brackets for Wall Mounting...36 Figure 7.
- Page 8 Figures...
- Page 9 Tables Table 1. Safety Symbols ...12 Table 2. System LED ...19 Table 3. Twisted Pair Port LEDs ...19 Table 4. SFP Port LED ...20 Table 5. IEEE 802.3af Class vs. Power Levels ...23 Table 6. Twisted Pair Cabling and Distances ...33 Table 7.
- Page 10 Tables...
-
Page 11: Preface
This guide provides the hardware installation instructions for your AT-GS900/8POE Fast Ethernet switch. This preface contains the following sections: “Safety Symbols Used in this Document” on page 12 “Where to Find Web-based Guides” on page 13 “Contacting Allied Telesis” on page 14... -
Page 12: Safety Symbols Used In This Document
Preface Safety Symbols Used in this Document This document uses the safety symbols defined in Table 1. Symbol Table 1. Safety Symbols Meaning Caution Performing or omitting a specific action may result in equipment damage or loss of data. Warning Performing or omitting a specific action may result in electrical shock. -
Page 13: Where To Find Web-Based Guides
AT-GS900/8POE Fast Ethernet Switch Installation Guide Where to Find Web-based Guides The installation and user guides for all Allied Telesis products are available in portable document format (PDF) on our web site at www.alliedtelesis.com. You can view the documents online or download... -
Page 14: Contacting Allied Telesis
Email and For Technical Support via email or telephone, refer to the Allied Telesis web site: www.alliedtelesis.com. Select your country from the list Telephone displayed on the website. Then select the appropriate menu tab. -
Page 15: Chapter 1: Overview
Chapter 1 Overview This chapter contains the follows sections: “Features” on page 16 “Port Descriptions” on page 17 “LEDs” on page 19 “Power Supply” on page 21 “Power over Ethernet” on page 22 “Ethernet Switching Basics” on page 24 “Network Topologies” on page 27... -
Page 16: Features
Chapter 1: Overview Features The AT-GS900/8POE Gigabit Ethernet switch is an unmanaged switch with the following features: Eight Auto-Negotiating 10/100/1000Base-T twisted pair ports with Power over Ethernet (PoE) capability One small form-factor pluggable (SFP) port to use as an uplink port System and port LEDs Power over Ethernet, IEEE 802.3af The AT-GS900/8POE Gigabit Ethernet switch can be used on a desktop,... -
Page 17: Port Descriptions
Port Descriptions The following sections describe the types of ports on the AT-GS900/8POE Gigabit Ethernet switch: “Twisted Pair Ports,” next “SFP Combo Port” on page 18 Twisted Pair The AT-GS900/8POE Gigabit Ethernet switch features eight 10/100/ 1000Base-T twisted pair ports. Ports The twisted pair ports feature 8-pin RJ-45 connectors. -
Page 18: Sfp Combo Port
Chapter 1: Overview PoE ports. SFP Combo Port The AT-GS900/8POE Gigabit Ethernet switch has one SFP port that can accommodate an optional Small Form-factor Pluggable (SFP) transceiver. The AT-GS900/8POE Gigabit Ethernet switch has one SFP combo port (Port 8) that can accommodate one optional Small Form-factor Pluggable (SFP) transceiver module. -
Page 19: Leds
LEDs The system and port LEDs on the front panel of the AT-GS900/8POE Gigabit Ethernet switch switch display the switch and its port status information. Table 2 describes the system LED. Each twisted pair port has two LEDs, as described in Table 3. AT-GS900/8POE Gigabit Ethernet Switch Installation Guide Table 2. - Page 20 Chapter 1: Overview Table 4 describes the SFP port LED. Table 4. SFP Port LED State Green A valid link is established on the SFP module in the SFP expansion slot. Blinking Frames are being transmitted/received on the Green SFP module in the SFP expansion slot. No link is established on the SFP module in the SFP expansion slot.
-
Page 21: Power Supply
Power Supply The AT-GS900/8POE Gigabit Ethernet switch has an internal power supply with a single AC power supply socket on the back panel which features autoswitch AC inputs. To power the switch on or off, connect or disconnect the power cord provided with the switch. AT-GS900/8POE Gigabit Ethernet Switch Installation Guide Note For the power requirements, refer to “Power Specifications”... -
Page 22: Power Over Ethernet
Chapter 1: Overview Power over Ethernet The twisted pair ports on the AT-GS900/8POE Gigabit Ethernet switch feature Power over Ethernet (PoE). PoE is a mechanism for supplying power to network devices over the same twisted pair cables used to carry network traffic. -
Page 23: Implementation
Note Power is supplied to the powered devices in the order that the ports are connected or on a first-come-first-served basis until the 65 watt limit is reached. If the switch is power cycled after the PoE devices are connected to the switch ports, the power is supplied to ports 1 through 8 in that order. -
Page 24: Ethernet Switching Basics
Chapter 1: Overview Ethernet Switching Basics An Ethernet switch interconnects network devices, such as workstations, printers, routers, and other Ethernet switches, so that they can communicate with each other by sending and receiving Ethernet frames. MAC Address Every hardware device on your network has a unique MAC address. This address is assigned to the device by the device’s manufacturer. -
Page 25: Store And Forward
end node can receive or transmit data, but not both simultaneously, the end node is operating in what is referred to as half-duplex mode. If an end node can both receive and transmit data simultaneously, the end node is said to be operating in full-duplex mode. Naturally, an end node capable of operating in full-duplex can handle data much faster than an end node that can only operate in half-duplex mode. -
Page 26: Back Pressure And Flow Control
Chapter 1: Overview Back Pressure To maintain the orderly movement of data between the end nodes, an Ethernet switch may periodically need to signal an end node to stop and Flow Control sending data. This can occur under several circumstances. For example, if two end nodes are operating at different speeds, the switch, while transferring data between the end nodes, might need to instruct the faster end node to stop transmitting data to allow the slower end node to catch... -
Page 27: Network Topologies
Network Topologies This section illustrates two network topologies that you can create with the AT-GS900/8POE Gigabit PoE switch: a power workgroup and collapsed backbone. Power The topology shown in Figure 3 is commonly referred to as a power workgroup topology. Each workstation or end-node is connected directly to Workgroup a port on the switch. -
Page 28: Poe Network Topology
Chapter 1: Overview PoE Network In the topology shown in Figure 4, an AT-GS900/8POE Gigabit Ethernet switch is connected to an AT-9424T/SP Gigabit Ethernet Switch and a Topology number of POE powered devices in different locations. AT-9424T CLASS 1 LASER PRODUCT AT-GS900/8POE 8 Port 10/100/1000 Mbps POE Switch with 1 Combo SFP Port PORT ACTIVITY... -
Page 29: Chapter 2: Installation
Chapter 2 Installation This chapter contains the following sections: “Reviewing Safety Precautions” on page 30 “Selecting a Site for the Switch” on page 32 “Planning the Installation” on page 33 “Unpacking the Switch” on page 34 “Installing the Switch on a Table or Desktop” on page 35 “Mounting the Switch on a Wall”... -
Page 30: Reviewing Safety Precautions
Note indicates that a translation of the safety statement is available in a PDF document titled “Translated Safety Statements” on the Allied Telesis website at www.alliedtelesis.com and on the documentation CD shipped with this product. Warning: Class 1 Laser product. - Page 31 AT-GS900/8POE Gigabit Ethernet Switch Installation Guide Warning: Operating Temperature. This product is designed for a maximum ambient temperature of 40° degrees C. All Countries: Install product in accordance with local and National Electrical Codes. Caution: The attached mounting brackets must be used to securely mount the device on the wall.
-
Page 32: Selecting A Site For The Switch
Chapter 2: Installation Selecting a Site for the Switch Observe the following requirements when choosing a site for the AT-GS900/8POE Gigabit Ethernet switch: If you plan to install the switch in an equipment rack, be sure that the rack is safely secured and that it will not tip over. Devices in a rack should be installed starting at the bottom, with the heavier devices near the bottom of the rack. -
Page 33: Planning The Installation
Planning the Installation Table 6 contains the cabling specifications for the twisted pair ports. Speed 10 Mbps 100 or 1000 Mbps AT-GS900/8POE Gigabit Ethernet Switch Installation Guide Table 6. Twisted Pair Cabling and Distances Type of Cable Category 3 or better 100-ohm shielded or unshielded twisted pair cable Category 5 or Category 5E (Enhanced) 100-ohm shielded or unshielded twisted... -
Page 34: Unpacking The Switch
Chapter 2: Installation Unpacking the Switch To unpack an AT-GS900/8POE Gigabit Ethernet switch, perform the following procedure: 1. Remove all components from the shipping package. 2. Place the switch on a level, secure surface. 3. Ensure the following hardware components are included in your switch package. -
Page 35: Installing The Switch On A Table Or Desktop
Installing the Switch on a Table or Desktop To install the switch on a table or desktop, perform the following procedure: 1. Remove all the items from the packaging and store the packaging material in a safe place. In the event a problem occurs and you need to return the unit, please use as much of the original shipping material as possible. -
Page 36: Mounting The Switch On A Wall
Chapter 2: Installation Mounting the Switch on a Wall You can mount the AT-GS900/8POE Gigabit Ethernet switch on the wall in a vertical position using the mounting brackets that are shipped with the switch. The wall-mounting screws, plastic anchors, and other materials necessary to mount the switch on a wall are not provided. -
Page 37: Figure 7. Mounting The Switch On The Wall
5. Mount the switch on the wall using the wall mounting screws (not provided), as shown in Figure 7. Figure 7. Mounting the Switch on the Wall 6. Refer to “Cabling and Powering on the Switch” on page 43 to complete the installation. -
Page 38: Installing The Switch In A Rack
Chapter 2: Installation Installing the Switch in a Rack To install the switch in a rack, perform the following procedure: 1. If attached, remove the rubber feet using a flat-head screwdriver. 2. Attach a mounting bracket (provided) to each side of the switch using the bracket mounting screws (provided), as shown Figure 8. -
Page 39: Figure 9. Mounting The Switch On The Rack
AT-GS900/8POE Gigabit Ethernet Switch Installation Guide Figure 9. Mounting the Switch on the Rack Warning: To prevent electric shock, do not remove the cover. No user-serviceable parts inside. This unit contains hazardous voltages and should only be opened by a trained and qualified technician. - Page 40 Chapter 2: Installation Refer to “Cabling and Powering on the Switch” on page 43 to complete the installation. Warning: Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to supply connections other than direct connections to the branch circuits (e.g., use of power strips).
-
Page 41: Installing An Optional Sfp Transceiver
You must install the transceiver before you connect cables to it. Note You must use the original shipping material if you need to return the module to Allied Telesis. Warning: An SFP transceiver can be damaged by static electricity. Be sure to observe all standard electrostatic discharge (ESD) precautions, such as wearing an antistatic wrist strap, to avoid damaging the transceiver. -
Page 42: Figure 10. Inserting The Sfp
Chapter 2: Installation 4. Slide the SFP transceiver into the SFP slot on the switch, as shown in Figure 10. For information about cabling for the SFP, refer to “Cabling an SFP Transceiver” on page 44. P O R T A C T IV IT 1 0 0 0 L IN K... -
Page 43: Cabling And Powering On The Switch
Cabling and Powering on the Switch This section contains the following procedures: “Cabling the Twisted Pair Ports,” next “Cabling an SFP Transceiver” on page 44 “Powering on the Switch” on page 45 Cabling the To connect to the 10/100Base-T twisted pair ports on the AT-FS708/POE switch, perform the following procedure: Twisted Pair Ports... -
Page 44: Cabling An Sfp Transceiver
Chapter 2: Installation Cabling an SFP To cable an SFP transceiver, perform the following procedure: Transceiver 1. Remove the dust cover from the SFP transceiver, as shown in Figure 12. Warning Class 1 laser product. Warning Do not stare into the laser beam. Note For information about the proper cable type, refer to the documentation that accompanied the SFP transceiver. -
Page 45: Powering On The Switch
2. Connect the fiber optic cable to the SFP transceiver, as shown in Figure 13. Figure 13. Connecting Fiber Optic Cables to the SFP Transceiver 3. Power on the end nodes. Powering on the To power on the AT-GS900/8POE Gigabit Ethernet switch, perform the following procedure: Switch 1. - Page 46 Chapter 2: Installation If the PWR LED is OFF, refer to Chapter 3, “Troubleshooting” on page The switch is ready for network operations.
-
Page 47: Chapter 3: Troubleshooting
If after following the instructions in this chapter you are unable to resolve the problem, contact Allied Telesis Technical Support for assistance. Refer to “Contacting Allied Telesis” on page 14 for contact information. Ensure that the power cord is securely connected to the power source and to the AC connector on the back panel of the switch. -
Page 48: Pd Error Led Is On
Chapter 3: Troubleshooting Verify that you are using the appropriate category of twisted pair cable: Category 3 or better for 10 Mbps operation and Category 5 and Category 5E for 100 Mbps operation. PD ERROR LED is On If the PD ERROR LED is on, indicating that there is a connection error to one of the PoE powered device connected to the switch ports, verify that the device is powered ON and is operating properly. -
Page 49: Appendix A: Technical Specifications
Appendix A Technical Specifications Physical Specifications Dimensions: Weight: Environmental Specifications Operating Temperature: Storage Temperature: Operating Humidity: Storage Humidity: Operating Altitude Range: Power Specifications AC Voltage/Frequency Requirements: AC Input Power Consumption: Available Power over Ethernet: IEEE 802.3af Class 3 (15.4 W): IEEE 802.3af Class 2 (7.3 W): IEEE 802.3af Mode: (W x D x H) -
Page 50: Safety And Electromagnetic Emissions Certifications
Appendix A: Technical Specifications Safety and Electromagnetic Emissions Certifications Immunity Electrical Safety Laser FCC Class A, EN55022 Class A, C-TICK EN55024 UL 60950-1 ( ), EN 60950-1 (TUV) or VDE, CE IEC/EN 60825-1, IEC/EN 60825-2... -
Page 51: Rj-45 Twisted Pair Port Connectors
RJ-45 Twisted Pair Port Connectors This section lists the connectors and connector pinouts for the AT-GS900/8POE Gigabit PoE switch and its components. Figure 15 illustrates the pin layout to an RJ-45 connector and port. Table 7 lists the RJ-45 pin signals when a twisted pair port is operating in the MDI configuration. - Page 52 Appendix A: Technical Specifications...
