Module Settings
JW2, JW3, JW4, and JW5: Leave these jumpers open, on positions 2 and 3.
J11 Terminals: Not connected.
Components
There are four green LEDs on the board, one for each signal zone. The LED will illuminate or flash following the
signal rate sent to its zone. It will be off when the system is normal and they will illuminate when a signal zone is
activated. The LED does not reflect what is happening on the signal zone, just that it is receiving data to activate that
signal zone.
Note: Jumpers JW2, JW3, JW4 and JW5 are positioned on pins 2 and 3 (right two pins with board
orientation as shown above) from factory.
Operation
There are two modes of operation for this module. The basic mode of operation does not involve any isolators
connected to the signal zones. For this case, leave jumpers JW2, JW3, JW4 and JW5 as they come on pins 2 and
3, and do not make any connection to terminal block J11. The second mode provides mode is used when isolators
are to be connected to the signal circuits. For further information on bell cut relays or isolators, please refer to the
specific fire alarm panel manual or the isolator instruction manual.
I solator Mode
Jumpers for the I solator Mode
JW2: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 1.
JW3: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 2.
JW4: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 3.
JW5: Place jumper over pins 2 and 3 for the ability to connect an isolator on Zone 4.
ATTENTI ON: Discard jumpers on zones that are not configured for isolators.
J11: Wire these terminals to an alarm relay. These may be tapped if more signal modules are used in this manner.
