FleX-Net™ Mass Notification System ( BBX-FXMNS) Enclosure
This enclosure can accommodate all existing modules, except the QMP-5101N Network Master Paging Control
module and the QMT-5302N Master Firefighters' Telephone. New models, QMP-5101NV vertical mounting master
paging microphone and QMT-5302NV Master Telephone panels are used instead to mount within the BBX-FXMNS
Enclosure. The BBX-FXMNS enclosure includes a backbox and a two part door and display deadfront chassis.
Figure 47: BBX-FXMNS Enclosure
22.4"
61.1"
62.7"
9"
7.6"
20"
Notes: When using the BBX-FMNS as a Mass Notification System (ACU) refer to Appendix I.
