Appendix A: Specifications
ANC-5000 Audio Controller Module
Current Consumption:
TNC-5000 Telephone Controller Module
Current Consumption:
Fan Damper Display Module ( FDX-008W/ FDX-008WKI )
24V DC nominal, range of 20 to 39V DC.
Current Consumption:
Digital Communicator Module ( UDACT-300A)
Transmit alarm, supervisory, and trouble to a central monitoring
station.
Current Consumption:
DSPL-420( DS) and DSPL- 2440 Displays
Current Consumption:
Compliance
System Model: FleX-Net™ Series Fire Alarm Control Panels FX-2003-12NDS, FX-2003-12NXTDS,
FX-2009-12NDS, FX-2017-12NDS and FX-2000MNS.
System Type: Local, auxiliary (using PR-300), remote protected premise station (using PR-300 or
UDACT-300A), central station protected premises (using UDACT-300A), Proprietary System (PPU) and
Smoke Control
Type of Service: A, M, WF, SS, PPU, MNS
Type of Signalling: Non-coded
Applicable Standards: NFPA 70 and 72, UL-864 R10, UL 2572, ULC S-524, ULC S-527-11
122
standby: 255 mA
alarm: 265 mA
standby: 195 mA
alarm: 215 mA
standby: 15mA Max.
alarm (all LEDs ON): 35mA Max.
standby: 45 mA
alarm: 120 mA
standby: 25mA and 35mA
alarm: 25mA and 30mA
RAXN- LCDG Annunciator
24V DC nominal.
Standby: 117 mA Max., All LED's "On": 150 mA Max
RAXN- LCD Annunciator
24V DC nominal, range of 20 to 39V DC.
Standby: 100 mA Max., All LED's "On": 150 mA Max
Adder Annunciator Module RAX- 1048TZDS
48 Display Points (TZ version has 48 extra trouble display points).
Current Consumption: standby: 139 mA
alarm: 1 zone LED active: 26 mA
2 zone LEDs active: 30 mA
3 zone LEDs active: 35 mA
4 zone LEDs active: 39 mA
48 zone LEDs active: 262 mA
Programmable I nput Sw itches Module ( I PS-2424DS)
Current Consumption: standby: 5 mA
alarm (one zone active): 22 mA
Programmable I nput Sw itches Module ( I PS-4848DS)
Current Consumption: standby: 10 mA
alarm (one zone active): 22 mA
