Figure 69:
Audio Paging Bus Wiring
Node 4
Node 3
Node 2
Audio Bus Specifications:
10V, 50 mA Maximum
Total cable resistance is: 90 ohms Max
18 gauge twisted pair wire
Audio Bus is power-limited and fully
supervised.
CLASS A WIRING
Paging
Bus Out
ANC-5000
Paging
Bus In
Paging
Bus Out
ANC-5000
Paging
Bus In
Paging
Bus Out
ANC-5000
Paging
Bus In
S - +
Paging
Bus Out
Paging
Bus In
Paging
Bus Out
Paging
Bus In
Paging
Bus Out
Paging
Bus In
Paging
Bus Out
S - +
Paging
Bus In
ANC-5000
CACF
Node 1
TM
FleX-Net
Installation and Operation Manual
ANC-5000
Node 5
ANC-5000
Node 6
Additional ANC-5000s
connected in between
ANC-5000
Last Node
103
