HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
PRM2 Register
• HT66F50/HT66F60
Bit 7
Name TP3�PS
R/W R/W
POR 0
Bit 7 TP31PS: TP3_1 Pin Remapping Control
0: TP3_1 on PD0
1: TP3_1 on PE3
TP30PS: TP3_0 Pin Remapping Control
Bit 6
0: TP3_0 on PD3
1: TP3_0 on PE5
TP21PS: TP2_1 Pin Remapping Control
Bit 5
0: TP2_1 on PC4
1: TP2_1 on PD4
Bit 4 TP20PS: TP2_0 Pin Remapping Control
0: TP2_0 on PC3
1: TP2_0 on PD1
Bit 3 TP1B2PS: TP1B_2 Pin Remapping Control
0: TP1B_2 on PC5
1: TP1B_2 on PE4
Bit 2 TP1APS: TP1A Pin Remapping Control
0: TP1A on PA1
1: TP1A on PC7
TP01PS: TP0_1 Pin Remapping Control
Bit 1
0: TP0_1 on PC5
1: TP0_1 on PD5
TP00PS: TP0_0 Pin Remapping Control
Bit 0
0: TP0_0 on PA0
1: TP0_0 on PC6
Rev. 2.50
6 5 4
TP30PS TP2�PS TP20PS
R/W R/W R/W
0 0 0
9�
3 2 1
TP�B2PS TP�APS TP0�PS
R/W R/W R/W
0 0 0
��ne 22� 20��
0
TP00PS
R/W
0
