• TM1BH Register – 10-bit ETM
Bit 7
Name —
R/W —
POR —
Bit 7~2 Unimplemented, read as "0"
Bit 1~0 TM1BH: TM1 CCRB High Byte Register bit 1~bit 0
TM1 10-bit CCRB bit 9~bit 8

Enhanced Type TM Operating Modes

The Enhanced Type TM can operate in one of five operating modes, Compare Match Output Mode,
PWM Output Mode, Single Pulse Output Mode, Capture Input Mode or Timer/Counter Mode. The
operating mode is selected using the TnAM1 and TnAM0 bits in the TMnC1, and the TnBM1 and
TnBM0 bits in the TMnC2 register.
ETM Operating Mode
CCRB Compare Match O�tp�t Mode
CCRB Timer/Co�nter Mode
CCRB PWM O�tp�t Mode
CCRB Single P�lse O�tp�t Mode
CCRB Inp�t Capt�re Mode
Rev. 2.50
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
6 5 4
— — —
— — —
— — —
CCRA
CCRA Compare
Timer/Counter
Match Output Mode
Mode
√ —
— √
— —
— —
— —
�52
A/D Flash MCU with EEPROM
3 2 1
— — D9
— — R/W
— — 0
CCRA Single
CCRA PWM
Pulse Output
Output Mode
Mode
— —
— —
√ —
— √
— —
"√": permitted; "—": not permitted
0
D8
R/W
0
CCRA Input
Capture Mode
—
—
—
—
√
