• HT66F30
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5~0 Data EEPROM address
Data EEPROM address bit 5~bit 0
• HT66F40
Bit 7
Name —
R/W —
POR —
Bit 7 Unimplemented, read as "0"
Bit 6~0 Data EEPROM address
Data EEPROM address bit 6~bit 0
• HT66F50/HT66F60
Bit 7
Name D�
R/W R/W
POR ×
Bit 7~0 Data EEPROM address
Data EEPROM address bit 7~bit 0
