TMPC0 Register
• HT66F20
Bit
7
Name
—
R/W
—
POR
—
Bit 7~6
Unimplemented, read as "0"
Bit 5
T1CP1: TP1_1 pin Control
0: Disable
1: Enable
Bit 4
T1CP0: TP1_0 pin Control
0: Disable
1: Enable
Bit 3~1
Unimplemented, read as "0"
T0CP0: TP0_0 pin Control
Bit 0
0: Disable
1: Enable
• HT66F30
Bit
7
Name
T�ACP0
R/W
R/W
POR
�
Bit 7
T1ACP0: TP1A pin Control
0: Disable
1: Enable
Bit 6
Unimplemented, read as "0"
Bit 5
T1BCP1: TP1B_1 pin Control
0: Disable
1: Enable
Bit 4
T1BCP0: TP1B_0 pin Control
0: Disable
1: Enable
Bit 3~2
Unimplemented, read as "0"
T0CP1: TP0_1 pin Control
Bit 1
0: Disable
1: Enable
Bit 0
T0CP0: TP0_0 pin Control
0: Disable
1: Enable
Rev. 2.50
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
6
5
4
—
T�CP�
T�CP0
—
R/W
R/W
�
—
0
6
5
4
—
T�BCP�
T�BCP0
—
R/W
R/W
—
0
�
�08
3
2
1
—
—
—
T0CP0
—
—
—
—
—
—
3
2
1
—
—
T0CP�
T0CP0
—
—
R/W
—
—
0
��ne 22� 20��
0
R/W
�
0
R/W
�
