ACERL Register
Bit
7
Name
ACE�
R/W
R/W
POR
�
Bit 7
ACE7: Define PA7 is A/D input or not
0: Not A/D input
1: A/D input, AN7
ACE6: Define PA6 is A/D input or not
Bit 6
0: Not A/D input
1: A/D input, AN6
Bit 5
ACE5: Define PA5 is A/D input or not
0: Not A/D input
1: A/D input, AN5
Bit 4
ACE4: Define PA4 is A/D input or not
0: Not A/D input
1: A/D input, AN4
Bit 3
ACE3: Define PA3 is A/D input or not
0: Not A/D input
1: A/D input, AN3
Bit 2
ACE2: Define PA2 is A/D input or not
0: Not A/D input
1: A/D input, AN2
ACE1: Define PA1 is A/D input or not
Bit 1
0: Not A/D input
1: A/D input, AN1
Bit 0
ACE0: Define PA0 is A/D input or not
0: Not A/D input
1: A/D input, AN0
ACERH Register
• HT66F60
Bit
7
Name
—
R/W
—
POR
—
Bit 7~4
Unimplemented, read as "0"
Bit 3
ACE11: Define PF1 is A/D input or not
0: Not A/D input
1: A/D input, AN11
Bit 2
ACE10: Define PF0 is A/D input or not
0: Not A/D input
1: A/D input, AN10
Bit 1
ACE9: Define PE7 is A/D input or not
0: Not A/D input
1: A/D input, AN9
ACE8: Define PE6 is A/D input or not
Bit 0
0: Not A/D input
1: A/D input, AN8
Rev. 2.50
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
6
5
4
ACE6
ACE5
ACE4
R/W
R/W
R/W
�
�
�
6
5
4
—
—
—
—
—
—
—
—
—
��4
3
2
1
ACE3
ACE2
ACE�
R/W
R/W
R/W
�
�
�
3
2
1
ACE��
ACE�0
ACE9
R/W
R/W
R/W
�
�
�
��ne 22� 20��
0
ACE0
R/W
�
0
ACE8
R/W
�
