Uart Data Transfer Scheme - Holtek HT66F20 Manual

To initiate a data transaction, the MCU master SPI needs to pull SCS to a low level first and then
also pull SCK low. The input data bit on SDI should be stable before the next SCK rising edge, as
the device will latch the SDI status on the next SCK rising edge. Regarding the SDO line, the output
data bit will be updated on the SCK falling edge. The master needs to obtain the line status before
the next SCK falling edge.
There are 16 bits of data transmitted and/or received by the SPI interface for each transaction. Each
transaction consists of a command phase and a data phase. When SCS is high, the SPI interface is
disabled and SDO will be set to a high impedance state.
After a complete transaction has been implemented, which requires 16 SCK clock cycles, the master
needs to set SCS to a high level in preparation for the next data transaction.
For write operations, the device will begin to execute the command only after it receives a 16-bit
serial data sequence and when the SCS has been set high again by the master.
For read operations, the device will begin to execute the command only after it receives an 8-bit
read command after which it will be ready to output data. If necessary, the master can de-assert the
SCS pin to abort the transaction at any time which will cause any data transactions to be abandoned.
UART Module External Pin Interfacing
To communicate with an external serial interface, the internal UART has two external pins known as
TX and RX. The TX pin is the UART transmitter serial data output pin if the corresponding control
bits named UARTEN in UCR1 register and TXEN in UCR2 register are set to 1. If the control bit
UARTEN or TXEN is equal to zero, the TX pin is in the state of high impedance. Similarly, the RX
pin is the UART receiver serial data input pin if the corresponding control bits named UARTEN and
RXEN in UCR1 and UCR2 registers are set to 1. If the control bit UARTEN or RXEN is equal to
zero, the RX pin is in the state of high impedance.

UART Data Transfer Scheme

The following block diagram shows the overall data transfer structure arrangement for the UART.
The actual data to be transmitted from the MCU is first transferred to the TXR register by the
application program. The data will then be transferred to the Transmitter Shift Register named TSR
from where it will be shifted out, LSB first, onto the TX pin at a rate controlled by the Baud Rate
Generator. Only the TXR register is accessible to the application program, the Transmitter Shift
Register is not mapped into the Data Memory area and is inaccessible to the application program.
Data to be received by the UART is accepted on the external RX pin, from where it is shifted in,
LSB first, to the Receiver Shift Register named RSR at a rate controlled by the Baud Rate Generator.
When the shift register is full, the data will then be transferred from the shift register to the internal
RXR register, where it is buffered and can be manipulated by the application program. Only the
RXR register is accessible to the application program, the Receiver Shift Register is not mapped
into the Data Memory area and is inaccessible to the application program. It should be noted that the
actual register for data transmission and reception, although referred to in the text, and in application
programs, as separate TXR and RXR registers, only exists as a single shared register physically. This
shared register known as the TXR/RXR register is used for both data transmission and data reception.
