PRM2 Register
• HT66F40
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 TP21PS: TP2_1 Pin Remapping Control
0: TP2_1 on PC4
1: TP2_1 on PD4
Bit 4 TP20PS: TP2_0 Pin Remapping Control
0: TP2_0 on PC3
1: TP2_0 on PD1
Bit 3 TP1B2PS: TP1B_2 Pin Remapping Control
0: TP1B_2 on PC5
1: TP1B_2 on PE4
Bit 2 TP1APS: TP1A Pin Remapping Control
0: TP1A on PA1
1: TP1A on PC7
TP01PS: TP0_1 Pin Remapping Control
Bit 1
0: TP0_1 on PC5
1: TP0_1 on PD5
TP00PS: TP0_0 Pin Remapping Control
Bit 0
0: TP0_0 on PA0
1: TP0_0 on PC6
Rev. 2.50
HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
6 5 4
— TP2�PS TP20PS TP�B2PS
— R/W R/W
— 0 0
96
3 2 1
TP�APS TP0�PS
R/W R/W R/W
0 0 0
��ne 22� 20��
0
TP00PS
R/W
0
