Holtek HT66F20 Manual page 222

TBC Register
Bit 7
Name TBON
R/W R/W
POR 0
Bit 7 TBON: TB0 and TB1 Control
0: Disable
1: Enable
TBCK: Select f
Bit 6
0: f
1: f
Bit 5~4 TB11~TB10: Select Time Base 1 Time-out Period
00: 4096/f
01: 8192/f
10: 16384/f
11: 32768/f
Bit 3 LXTLP: LXT Low Power Control
0: Disable
1: Enable
Bit 2~0 TB02~TB00: Select Time Base 0 Time-out Period
000: 256/f
001: 512/f
010: 1024/f
011: 2048/f
100: 4096/f
101: 8192/f
110: 16384/f
111: 32768/f
