Holtek HT66F20 Manual page 213

HT66F20/HT66F30/HT66F40/HT66F50/HT66F60
HT66FU30/HT66FU40/HT66FU50/HT66FU60
A/D Flash MCU with EEPROM
MFI0 Register
• HT66F20/HT66F30
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
Bit 5 T0AF: TM0 Comparator A match interrupt request flag
0: No request
1: Interrupt request
Bit 4 T0PF: TM0 Comparator P match interrupt request flag
0: No request
1: Interrupt request
Bit 3~2 Unimplemented, read as "0"
T0AE: TM0 Comparator A match interrupt control
Bit 1
0: Disable
1: Enable
T0PE: TM0 Comparator P match interrupt control
Bit 0
0: Disable
1: Enable
• HT66F40/HT66F50/HT66F60
Bit 7
Name T2AF
R/W R/W
POR 0
Bit 7 T2AF: TM2 Comparator A match interrupt request flag
0: No request
1: Interrupt request
Bit 6 T2PF: TM2 Comparator P match interrupt request flag
0: No request
1: Interrupt request
Bit 5 T0AF: TM0 Comparator A match interrupt request flag
0: No request
1: Interrupt request
Bit 4 T0PF: TM0 Comparator P match interrupt request flag
0: No request
1: Interrupt request
Bit 3 T2AE: TM2 Comparator A match interrupt control
0: Disable
1: Enable
T2PE: TM2 Comparator P match interrupt control
Bit 2
0: Disable
1: Enable
T0AE: TM0 Comparator A match interrupt control
Bit 1
0: Disable
1: Enable
Bit 0 T0PE: TM0 Comparator P match interrupt control
0: Disable
1: Enable
Rev. 2.50
6 5 4
— T0AF T0PF
— R/W R/W
— 0 0
6 5 4
T2PF T0AF T0PF
R/W R/W R/W
0 0 0
2�3
3 2 1
— — T0AE
— — R/W
— — 0
3 2 1
T2AE T2PE T0AE
R/W R/W R/W
0 0 0
��ne 22� 20��
0
T0PE
R/W
0
0
T0PE
R/W
0
