Advanced Poly-Packaging Advanced Poly-Bagger T-1000-S18H Operation Manual page 51

PLC Memory
Figure 3 - 49
External Storage
The Memory Stick contains several types of data from the machine. The Bagger Settings are stored, similar to the
information in PLC Storage. There are also files for the additional functionality of Recipe Management, and
information on Alarm and Production Data. To access this information, plug in the memory stick from the bagger
to your PC and open the DAT0000 folder. There will be a list of folders that have been set up by the touch screen
program, (see Figure 3 - 50). The two folders that contain the Recipe Data and Production Data are called Recipe
and Sample.
Inside DAT000 Folder:
51
The Program File contains the system
files, user-created instructions (Ladder
Logic), and sub-routines.
Contains the information required for
operation of the Program File, organized
by data type.
Figure 3 - 50
