5.12 Sealer Frame Assembly
ITEM
QTY.
NO.
1
1
TP-T1MB00200
2
1
TP-T1MD000276
2
1
TP-T1MD00276NB-1
2
1
TP-T1MD000276-2
2
1
TP-T1MD000276-3
3
1
TP-T1MD000275
3
1
TP-T1MD00275NB-1
3
1
TP-T1MD000275-2
3
1
TP-T1MD000275-3
4
1
TP-T1MD00277NB
5
2
TP-402186
6
2
TP-107127-1
7
2
TP-401277
8
2
TP-403245
9
2
TP-T1MB00057
10
1
TA-T10009
11
1
TA-T10006
12
3
TP-211374
13
1
TP-T1MB00164
14
2
TP-101132
15
2
TP-107228
16
2
TP-107227
17
2
TP-401257
18
4
TP-107160
19
2
TP-T1MB00027
20
1
TP-T1MB00005
21
1
TP-T1MB00107
22
1
TP-102254
23
2
TP-T1MB00033
23
2
TP-T1MB00033-1
23
2
TP-T1MB00033-2
23
2
TP-T1MB00033-3
24
1
TA-T10005
25
1
TP-T1MB00010
26
1
TP-403244
26
1
TP-403146
26
1
TP-403242
26
1
TP-403241
27
1
TP-T1MB00016
:
Drop Frame
P/N: TA-T10280-S14
PART NO
SEALER FRAME
NBO INTERNAL GUARD (4.25" PASS-THROUGH)
NBO INTERNAL GUARD (5.25" PASS-THROUGH)
NBO INTERNAL GUARD (6.25" PASS-THROUGH)
NBO INTERNAL GUARD (7.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (4.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (5.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (6.25" PASS-THROUGH)
BOTTOM INTERNAL GUARD (7.25" PASS-THROUGH)
SHORT INTERNAL GUARD
FLOW CONTROL, #10-32
BRONZE BUSHING
ELBOW, 1/4 TUBE
AIR CYLINDER
HEATER BAR YOKE
PTFE GUIDE SUB-ASSEMBLY
HEATER BAR SUB-ASSEMBLY
MAGNET, ROUND
PIVOT CLAMP
NUT, ACORN 5/16-18
BUSHING, NYLON FLANGE
BUSHING, THRUST NYLON
ELBOW, 1/4" TUBE x 1/8 NPT
PTFE COATED BUSHING
GRIPPER SPACER
FRONT GRIPPER PLATE
MAGNETIC SENSOR HOUSING
WASHER, FENDER
SEAL GUIDE ROD (4.25" Pass-Through)
SEAL GUIDE ROD (5.25" Pass-Through)
SEAL GUIDE ROD (6.25" Pass-Through)
SEAL GUIDE ROD (7.25" Pass-Through)
PRESSURE BAR SUB ASSEMBLY
SEALER ROD TIE
CYLINDER (4.25" Pass-Through)
CYLINDER (5.25" Pass-Through)
CYLINDER (6.25" Pass-Through)
CYLINDER (7.25" Pass-Through)
SEAL CYLINDER MOUNTING BLOCK
DESCRIPTION
126
