Advanced Poly-Packaging Advanced Poly-Bagger T-1000-S18H Operation Manual page 128

*Note: If you purchased the T-1000-S14 with a Standard Frame instead of a Drop Frame, your part numbers for the Standard Sealer Frame Assembly are the
same as those listed above with the exception of Item 30 TP-104210 Spacer, Item 31 TP-T1MO00129 Drop Frame Face Plate and Item 32 TP-T1MB00023 Drop
Frame Spacer. Those three parts are not included in the Standard Frame Sealer Frame Assembly.
*Note: Items 2, 3, 23, 26, and 29 will vary depending upon the Pass-Through size of the Bagger. Please note this when ordering parts from the Bill of Materials
shown above. For example, a Bagger with a 6.25" Pass-Through will use NBO Internal Guard TP-T1MD000276-2, Bottom Internal Guard TP-T1MD000275-2,
Seal Guide Rod TP-T1MB00033-2, Cylinder TP-403242, and Shield Mounting Rod TP-T1MB00144-2.
128
Note: The hardware that goes with
item # 16 is stacked in the order of
Bushing Thrust Nylon (item# 16),
3/8 Flat Washer (item# 53), 3/8
Internal Toothed Lock Washer
(item# 54), then 3/8-16 Hex Jam
Nut.
SEALER FRAME ASSEMBLY
