5.2 Base Assembly

ITEM
QTY.
NO.
1 1
2 1
3 2
4 2
5 2
6 2
7 2
111
P/N: TA-T10200
PART NO
TP-T1MA00051
TP-T1MA00051-1
TP-106094
TP-106119
TP-109148
TP-110756
TP-110763
DESCRIPTION
LOWER BASE WELDMENT
LOWER COLUMN
STUD, FLOOR LEVELER
SPRING PIN
HAND KNOB
CASTER, SWIVEL
CASTER, RIGID
