5.6 Dancer Assembly
ITEM
QTY.
NO.
1
1
TP-T1MA00069-1
2
1
TP-C1MA00069-2
3
1
TA-T10011
4
1
TP-T1MA00073
5
2
TP-504132
6
1
TP-T1MA00115
7
2
TP-104148
8
3
TP-101141
9
2
TP-T1MA00049
10
2
TP-103307
11
2
TP-106106
12
2
TP-109212-1
115
P/N: TA-T10220
PART NO
DANCER SIDE PLATE
DANCER SIDE PLATE
DANCER GUIDE SUB-ASSEMBLY
BAG ROLL SHAFT
CAM FOLLOWER
BELT TENSION STRAP & SPRING
SPACER
LOCKNUT, HEX #10-24
FILM TENSION HUB
SCREW, SHOULDER 1/4"D X 1-1/4"L X 10-24
SPRING PIN
"T" KNOB
DESCRIPTION
